SAMI-603

SAMI-603 is an installation audio mixer in standard rack format, featuring 1 MIC input + 4 MIC/LINE Stereo inputs + 1 LINE Stereo input and 3 outputs that can be configured as 1 stereo couple + 1 mono or 3 independent mono. Each output can get a dedicated mix from the available inputs and has a 3-band tone control. Talkover (priority) function is assignable to each input from IN1 to IN5 over the mix output buses. ST/MONO mix switch for the A/B outputs and MUTE port for external dry contact triggering.

• 6 input channels, 3 outputs 19” installation mixer
• 4 MIC/LINE stereo inputs
• 1 LINE stereo input
• 1 MIC input
• 1 stereo output or 2 x mono output (A and B outputs)
• 1 mono output (C output)
• Independent inputs routing for zones A, B, C
• 1 AUX/REC output
• Independent 3-band EQ control for outputs A/B and output C
• MUTE remote control input enabled by external dry contact closure for connecting fire detection systems and other safety devices.
• Switchable talkover function, from IN1 to IN5 over A, B, C outputs

Applications

Retail   Education   Corporate   Sports & Wellness   Hospitality
